ESPECIFICACIONES TÉCNICAS
POTENCIA
RIDE ALPHA DH 40 40 mm extension, direct mount, 31.8 mm
CADENA
KMC X11EL Black
ASIENTO
FIZIK Gravita Alpaca X5 MG rails, flexible "wings"
POSTE DE ASIENTO
RIDE ALPHA Super Light 31.6 mm, 250 mm length
GUÍA CADENA
E13 LG1 + Bottom Guide 32-34t
Talla
M
Talla
L
Talla
XL
Talla
S
CUADRO
Supreme DH V5 29/27, 220 mm travel on S / M / L / XL 29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
AMORTIGUADOR
FOX DHX 2 Performance Elite 250 x 75 mm, Rebound. Spring rates: 400 lbs on S, 450 lbs on M, 500 lbs on L, 500 lbs on XL
HORQUILLA
FOX 40 Performance, 203 mm travel 29", Grip damper, LSC, LSR, Float Evol. Boost (20 x 110 mm), 52 mm offset, 2 Tokens
DIRECCION
ACROS ZS56 / ZS56
VOLANTE
RIDE ALPHA R27 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
PUÑOS
ODI Longneck Soft pro compound, single clamp, black
FRENOS
TRP DH-R Evo, 4 pistons Rotor: TRP R1 223 mm, 6-bolt
PULSADOR
SRAM GX DH 7 sp
DESVIADOR TRASERO
SRAM GX DH 7 sp
CAJA DE PEDALIER
SRAM DUB Pressfit
BIELAS / PLATO
TRUVATIV Descendant DH, 165 mm crank arms, DUB Chainring: TRUVATIV Descendant DH X-Sync, 34t
CASSETTE
E13 LG1 PLUS DH 7s, 9-21t DM Cassette
AROS
E13 LG1 PLUS DH REAR: 27.5'', 32h, 30 mm inner width on S / M / L / XL - FRONT: 29'', 32h, 30 mm inner width on S / M / L / XL
BUJE
Rear: E13 LG1 PLUS DH - Front: E13 LG1 PLUS DH Rear: 32h, sealed bearings, 12 x 157 mm, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, black
LLANTAS
Rear: MAXXIS DHR II - Front: MAXXIS Assegai REAR: 27.5'' x 2.4'', WT, 3C MaxxGrip, DH Casing, Tubeless Ready on S / M / L / XL - FRONT: 29" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless Ready on S / M / L / XL
TEMPORADA
2023
